The main features of the BRN-13DH-2 double head copper middle pulling machine are:
This product is designed to absorb and digest the international advanced level of high-speed multi head copper wire drawing machine technology. It can draw 2 copper wires together, with the characteristics of high production efficiency, low production cost, and high economic benefits.
1. The host casing is an integrated casting part, using imported NSK or NTN brand bearings and high-precision hard tooth helical gear transmission (the tooth surface is machined and formed by a German gear grinding machine), with high and low gear switching (which can effectively improve the output torque of the equipment). The cable oil tank cover is sealed with a double-layer cover, and the door cover material is stainless steel. The equipment has a beautiful appearance, advanced structure, low operating noise, high production efficiency, and high economic benefits;
2. The wire drawing tower wheel is made of carbon fiber material, which has good wear resistance and long service life; Immersion cooling of the wire drawing part can provide optimal cooling and lubrication for the wire drawing die and copper wire, effectively extending the service life of the wire drawing die and tower wheel;
3. There is a space between the tower wheel box and the gearbox to prevent the infiltration and mixing of drawing fluid and gearbox oil. Multiple seals are adopted in the design and assembly to prevent infiltration.
4. Adopting a pneumatic end shaft winding machine, the upper and lower clamping and relaxation of the wire reel are controlled by pneumatic control, and the wire reel has anti reverse function when clamped; The width of the cable is adjusted by electric means, which is convenient to operate and effectively reduces the workload of workers;
5. The whole machine adopts PLC+human-machine interface coordinated control, Huichuan series variable frequency speed control, speed synchronization adjustable, and is equipped with automatic shutdown functions such as reaching meters, breaking wires, and faults.
